The Arctic innovation

As a pioneer, Pleiger is launching the electro-hydraulic drive on the market. Its further development into the EHS-EX opens up new doors for our customers.

Our EHS Power Pack for use down to -55°C

It impresses with the following features:

Suitable for installations with temperatures up to 25°C
Available in special versions for Arctic conditions down to -55°C!
Suitable for on-deck mounting
Available with quick-closing function
Closing time according to your requirements (approx. 6 to 30 sec.)
Available with directly mounted hand pump
With or without built-in heating

For installation on:

Ball valves
Butterfly valves – cryogenic valves

Possible Operation / Functions

Double- and single-acting
Open/Close or continuous position indication

The sophisticated design of our EHS-EX Power Pack, in combination with our extensive range of hydraulic actuators, offers you a unique solution for your individual requirements.

Double-acting

Type: EHS-EXD/15 … 1400
Torque: 174 Nm … 14,000 Nm
Functionality: Open/Close or continuous position indication

Single-acting

Type: EHS-EXSG/15 … 1400
Torque "Close": 174 Nm … 14,000 Nm
Torque "Open": 73 Nm … 6,625 Nm
Functionality: Open/Close or continuous position indication

Explosion-proof design

II 2G Ex d IIC T4 at -55°C / +70°C
II 2G Ex d IIC T6 at -25°C / +40°C

Application example

Installation types:

Dry
Submersed or submerged
"On-deck" installation.
